Genuine Ram 1500 Control Arm
Suspension Arm- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
63 Control Arms found
Ram 1500 Front Lower Control Arm Right
Part Number: 68298346AB$451.69 MSRP: $694.00You Save: $242.31 (35%)
Ram 1500 Suspension Control Arm Front
Part Number: 55398376AB$486.51 MSRP: $694.00You Save: $207.49 (30%)
Ram 1500 Suspension Control Arm Front
Part Number: 4877158AH$465.91 MSRP: $716.00You Save: $250.09 (35%)
Ram 1500 Suspension Control Arm Rear
Part Number: 68264947AA$174.41 MSRP: $263.00You Save: $88.59 (34%)
Ram 1500 Suspension Control Arm Left
Part Number: 4877159AD$316.94 MSRP: $716.00You Save: $399.06 (56%)
| Page 1 of 4 |Next >
1-20 of 63 Results
Ram 1500 Control Arm
The Control Arm is used in Ram 1500 for the connection of chassis to wheel assemblies, it provides easy suspension movements and weight balance around the turn. Usually an A-arm, the Control Arm attaches to the frame on one end and the wheels on the other so as to control radial movement but needs more links to control the to and fro movement. Year model Ram 1500 has adopted different sort of control arms for MacPherson Stut Front suspension where the track control arm lies in perpendicular position with the vehicle axis. Such designs come with a diagonal radius rod that helps in eliminating any form of movement that is undesirable. The basic difference between control arm types is the construction, while the A-arm restricts lateral movement and demands extras like control arms containing three links and offering triangulated structure with far more maneuverability, similar to the shape of a wishbone.
Looking for affordable and high-quality auto parts? Then you have already arrived at the proper online shop. We offer all Ram 1500 Control Arm at great affordable prices. Moreover, all genuine Ram 1500 Control Arm come with a manufacturer's warranty. In the long run, you would realize you have saved a lot of trouble and money with OEM parts from here.
Ram 1500 Control Arm Parts Questions & Experts Answers
- Q: How to Remove and Install a Control Arm on Ram 1500?A: This procedure is for models with independent front suspension. To remove the control arm, start by loosening the wheel lug nuts and raising the vehicle on jackstands. Remove the wheel and then loosen the nut on the upper balljoint stud. Use a balljoint removal tool to disconnect the balljoint from the steering knuckle. If you don't have the proper tool, a picklefork type balljoint separator can be used, but it may damage the balljoint boot. If necessary, remove the brake disc for clearance. Detach the wiring harness from the control arm. Remove the nuts and pivot bolts that attach the control arm to the frame. Pull the upper arm from its frame brackets. To install the control arm, reverse the removal steps. Tighten all fasteners, but don't tighten the pivot bolt nuts until the vehicle is at normal ride height. If needed, simulate normal ride height by raising the outer end of the lower control arm with a floor jack. Install the wheel and lug nuts, lower the vehicle, and tighten the lug nuts. Finally, have the front end alignment checked and adjusted if necessary.
