Chrysler 5154199AB Brake Hub And Bearing

You can Select Your Vehicle to check if 5154199AB fits your vehicle.

To service rear wheel bearings, start with the vehicle on jack stands. Check each wheel for noise and movement. Remove the wheel and, if applicable, the caliper. Remove the grease cap, cotter pin, lock, and hub nut from the hub. Extract the outer bearing, dust seal, and inner bearing. Clean these parts with solvent and inspect for defects. Pack the bearings with high-temperature grease and apply a thin coat to the spindle. Install the grease-packed bearings, new dust seal, washer, and nut. Spin the drum/hub to seat the bearings and recheck the nut's tightness.

After raising the vehicle, remove the driveaxle hub nut and washer. Push the driveaxle in until it's free of the hub, which may require tapping with a brass drift punch and hammer. Remove the cotter pin and nut, and use a puller to disconnect the tie-rod end from the steering knuckle. Secure the tie-rod aside with wire. Then, disconnect the brake hose bracket from the strut, remove the caliper and brake pads, and detach the caliper mounting bracket from the steering knuckle. Hang the caliper out of the way with wire.
