Jeep 68252670AO Engine Oil

You can Select Your Vehicle to check if 68252670AO fits your vehicle.

To replace the oil pan pull off the timing chain cover then take out the oil pump cover bolted to the timing chain cover by applying power on the Torx drive socket. Shine all of them in the solvent and inspect the rotor, pump cover and timing chain cover for any nicks, scratches or burrs the entire assembly should be replaced. With the straightedge utilize the feeler gauge to measure oil pump cover for warpage; if in excess of limit, replace the pump. Check the thickness of the outer rotor and replace the pump if it is anything below the thickness should be. Measuring the thickness of the inner rotor with a micrometer: replace the pump, if this diameter is less than the allowable one. Fit the outer rotor into the timing chain cover/oil pump housing and check the gap when the rotor would be in its highest position; if this gap is larger than the maximum permissible gap, then change the pump. Insert the inner rotor in the oil pump assembly and check the leakage between the lobes of inner and outer rotor replacing the pump in the event leakage is greater than mentioned above, be certain that the arrow marked on the inner rotor is up. Place a straightedge on the face of the oil pump assembly, and using a micrometer measure the distance between the surface of the pump and the rotors; if the distance is more than the recommended limit you replace the pump. On installations, tighten the pump cover bolts to the torque of your choice, ensure that the flats in the rotor slotting match those of the crankshaft when fixing the pump and then fit the timing chain cover and fixed by the right torque. The following steps involve the reversal of the Remove steps covered above in order of installation.

Inspect the oil pump cover for warpage using feeler gauges and a straightedge.

Clean all components with solvent and inspect for wear and damage.
