How do you replace wiper motors on Chrysler PT Cruiser?

First of all, turn the ignition key out of the key lock cylinder. The positions of the wiper arms shall be marked and then the wiper arms are pulled away by drawing a line across the stud and the wiper arm with paint so as to ensure they can be reinstalled in the same positions to the windshield. Second, one has to take off the cowl grille screens. Pull off the windshield wiper motor connector, and unbolt the windshield wiper module assembly which entails, removing the wiper motor electric connector, and removing the bolts, those at the right and left sides of the wiper module respectively. Next to that, take out the crank arm nut together with the wiper motor mounting bolts and after that you can disconnect the motor from the assembly. For installation, carry out the process in the reverse of above removal process; make sure to issue power to the wiper motor on and off to check that it is in the Park position before re-installing the wiper arms. As for the rear, it is necessary, first of all, to turn the ignition key counterclockwise until it falls out of the key lock cylinder. Locate the wiper arm for the rear windscreen and then unclip it, it may be necessary to use a battery terminal puller or similar device to pull the arm from the wiper shaft. Liftgate trim panel has to be unbolted, the wiper motor harness connector has to be unplug, the mounting bolts of the rear wiper motor assembly have to be loosened and finally the rear wiper motor assembly has to be detached. Last but not the least, for the installation procedure, reverse all the steps given for the removal process but always switch 'ON' the wiper motor and 'OFF' it to ensure that the motor is in the 'Park Position' before proceeding to reinstall the wiper arms.

Genuine Chrysler PT Cruiser Wiper Motor

Windshield Wiper Motor

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

10 Wiper Motors found

View related parts
Chrysler PT Cruiser Motor-LIFTGATE WIPER
Part Number: 4857931AC
$202.36 MSRP: $304.00
You Save: $101.64 (34%)
ADD TO CART
Product Specifications
- Other Name: Motor Liftgate Wiper
- Replaced by: 4857931AD
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2007 Chrysler PT Cruiser | Base, GT, Limited, Touring | 4 Cyl 2.4L
View related parts
Chrysler PT Cruiser Motor-LIFTGATE WIPER
Part Number: 4857931AD
$202.36 MSRP: $304.00
You Save: $101.64 (34%)
ADD TO CART
Product Specifications
- Other Name: Motor Liftgate Wiper; Rear Motor, Wiper Motor
- Replaces: 4857931AC, 4857931AA, 4857931AB
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2004-2010 Chrysler PT Cruiser | Base, Classic, GT, LX, Limited, Touring | 4 Cyl 2.4L
View related parts
Chrysler PT Cruiser Motor-LIFTGATE WIPER
Part Number: 4857931AA
$202.36 MSRP: $304.00
You Save: $101.64 (34%)
ADD TO CART
Product Specifications
- Other Name: Motor Liftgate Wiper
- Replaced by: 4857931AD
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2004-2005 Chrysler PT Cruiser | Base, GT, Limited, Touring | 4 Cyl 2.4L
View related parts
Chrysler PT Cruiser Motor-LIFTGATE WIPER
Part Number: 4857931AB
$202.36 MSRP: $304.00
You Save: $101.64 (34%)
ADD TO CART
Product Specifications
- Other Name: Motor Liftgate Wiper
- Replaced by: 4857931AD
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2006 Chrysler PT Cruiser | Base, GT, Limited, Touring | 4 Cyl 2.4L
View related parts
Chrysler PT Cruiser Motor-Windshield WIPER
Part Number: 5175910AA
$109.45 MSRP: $164.00
You Save: $54.55 (34%)
ADD TO CART
Product Specifications
- Other Name: Motor Windshield wiper; Front Motor, Motor, Wiper Motor
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2006-2010 Chrysler PT Cruiser | Base, Base Convertible, Classic, GT, GT Convertible, Limited, LX, Touring, Touring Convertible | 4 Cyl 2.4L
View related parts
Chrysler PT Cruiser Motor-Windshield WIPER
Part Number: 5142422AA
$112.91 MSRP: $143.68
You Save: $30.77 (22%)
ADD TO CART
Product Specifications
- Other Name: Motor Windshield wiper
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2005 Chrysler PT Cruiser | Base, Base Convertible, GT, GT Convertible, Limited, Touring, Touring Convertible | 4 Cyl 2.4L
View related parts
Chrysler PT Cruiser Motor-Windshield WIPER
Part Number: 5018450AA
Product Specifications
- Other Name: Motor Windshield wiper; Front Motor, Motor, Wiper Motor
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2001-2004 Chrysler PT Cruiser | Base, Base Convertible, GT, GT Convertible, Limited, Touring, Touring Convertible | 4 Cyl 2.4L
View related parts
Chrysler PT Cruiser Motor-LIFTGATE WIPER
Part Number: R4717710AD
Product Specifications
- Other Name: Motor Liftgate Wiper
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2003 Chrysler PT Cruiser | Base, GT, Limited, Touring | 4 Cyl 2.4L
View related parts
Chrysler PT Cruiser Motor-LIFTGATE WIPER
Part Number: 4717710AD
Product Specifications
- Other Name: Motor Liftgate Wiper; Rear Motor, Wiper Motor
- Replaces: 5018406AC, 5018406AA, 4717710AB, 5018406AB, 4717710AC, 5073282AA
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2001-2003 Chrysler PT Cruiser | Base, GT, Limited, Touring | 4 Cyl 2.4L
View related parts
Chrysler PT Cruiser Motor-LIFTGATE WIPER
Part Number: 5018406AA
Product Specifications
- Other Name: Motor Package Liftgate wiper
- Replaced by: 4717710AD
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2001-2002 Chrysler PT Cruiser | Base, Limited, Touring | 4 Cyl 2.4L

Chrysler PT Cruiser Wiper Motor

Wiper Motor in Chrysler PT Cruiser cars is such a small yet very important automotive part in the sense that it is responsible for the control of the windshield wipers so that rain and other micro particles that obscure visibility can be wiped off. This electric motor rotates at different speeds to enable drivers change the speed of wiper in relation to the weather. Original Chrysler PT Cruiser Wiper Motors are possible to be bought but the refurbished ones are also available in the market. New Wiper Motors are usually purchased directly from the manufacturer while refurbished means that it is a used one that has been upgraded with new parts making it be as efficient as the new one in the market. This variety means that everyone with a Chrysler PT Cruiser will be in a position to find the optimal solution in terms of maintenance of their wipers while at the same time having a more reliable wiper at their disposal.

Looking for affordable and high-quality auto parts? Then you have already arrived at the proper online shop. We offer all Chrysler PT Cruiser Wiper Motor at great affordable prices. Moreover, all genuine Chrysler PT Cruiser Wiper Motor come with a manufacturer's warranty. In the long run, you would realize you have saved a lot of trouble and money with OEM parts from here.

Chrysler PT Cruiser Wiper Motor Parts Questions & Experts Answers

Motor-LIFTGATE WIPER
4857931AD
Q: How do you replace wiper motors on Chrysler PT Cruiser?
A: First of all, turn the ignition key out of the key lock cylinder. The positions of the wiper arms shall be marked and then the wiper arms are pulled away by drawing a line across the stud and the wiper arm with paint so as to ensure they can be reinstalled in the same positions to the windshield. Second, one has to take off the cowl grille screens. Pull off the windshield wiper motor connector, and unbolt the windshield wiper module assembly which entails, removing the wiper motor electric connector, and removing the bolts, those at the right and left sides of the wiper module respectively. Next to that, take out the crank arm nut together with the wiper motor mounting bolts and after that you can disconnect the motor from the assembly. For installation, carry out the process in the reverse of above removal process; make sure to issue power to the wiper motor on and off to check that it is in the Park position before re-installing the wiper arms. As for the rear, it is necessary, first of all, to turn the ignition key counterclockwise until it falls out of the key lock cylinder. Locate the wiper arm for the rear windscreen and then unclip it, it may be necessary to use a battery terminal puller or similar device to pull the arm from the wiper shaft. Liftgate trim panel has to be unbolted, the wiper motor harness connector has to be unplug, the mounting bolts of the rear wiper motor assembly have to be loosened and finally the rear wiper motor assembly has to be detached. Last but not the least, for the installation procedure, reverse all the steps given for the removal process but always switch 'ON' the wiper motor and 'OFF' it to ensure that the motor is in the 'Park Position' before proceeding to reinstall the wiper arms.
