Diagram (1 of 1): BRAKES, SERVICE BOOSTER--POWER BRAKE B BODY

1990 Dodge Ram Van Booster - Power Brake Diagram

Enlarge Diagram

Sort by:

Ref No.

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

1
152344
NUT
- Require Quantity: 4
- Package Quantity: 1
$6.25 $4.91
1
Add To Cart

2
4088816
SEAL

3
4294036
CLIP
- Replaced By: 4581512AA
$2.35 $1.72
1
Add To Cart

4
2460609
BOLT, w/O-Ring

5
6029799
BOLT, 3/8 - 16 x .75
- Require Quantity: 2
- Package Quantity: 1

6
4088817
SHAFT, Brake Booster Bellcrank Pivot

7
52004628
BRACKET, Booster Mounting to Dash

8
2467770
BUSHING, Bellcrank Pivot Shaft
- Require Quantity: 2
- Package Quantity: 1

9
4088813
BELLCRANK, Brake Booster and Pedal Push Rod

10
4294160
ROD, Pedal to Bellcrank Push

11
9417507
PIN, Spring

12
J0120396
WASHER

13
905206
WASHER, Spring

14
2955739
BOOT, Brake Booster B/Crank to Pedal Push Rod

15
4115207
PLATE, Mounting Bracket

16
6500230
NUT
- Require Quantity: 2

17
4485124
BOOSTER, Brake w/3600 Lb. Frt. Axle
BOOSTER, Brake w/3600 Lb. Frt. Axle
17
52004629
BOOSTER, Brake w/3600 Lb. Frt. Axle
- w/4000 Lb. Frt. Axle, w/Dana 60 Rear Axle
- Fitting Vehicle Options: 3, B

18
152347
NUT, 1990-91
1992-93
18
6023110
NUT, 1990-91
- NUT, 1990-91

19
9436885
SCREW and WASHER

20
4443176
HOSE, Brake Booster to Manifold (Roll Stock)
- Replaced By: HFV00516

21
4485529
FILTER, Brake Booster Hose

22
2448761
CLAMP
- Require Quantity: 2
- Package Quantity: 1
- Replaced By: 33000784
$4.95 $3.28
1
Add To Cart

2830370
GROMMET, Check Valve

Genuine Mopar Parts, the Right Choice

MoparPartsGiant.com offers the wholesale prices for genuine 1990 Dodge Ram Van parts. Parts like Booster - Power Brake are shipped directly from authorized Mopar dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 6 Cyl 3.9L, 8 Cyl 5.2L, 8 Cyl 5.9L. Transmission: 3-Speed Automatic Transmission, 4-Speed Automatic Transmission, 5-Speed Manual Transmission.
