Diagram (1 of 1): REAR AXLE DIFFERENTIAL, LOCKING DANA MODEL 35 CHEROKEE, GRAND CHEROKEE

1994 Jeep Cherokee Differential - Locking Diagram

Enlarge Diagram

Sort by:

Ref No.

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

1
J3182601
NUT, Pinion
- Replaced By: 4720895AB
$26.05 $17.46
1
Add To Cart

2
83503318
YOKE, Pinion
w/Rear Drum Brakes
Fitting Vehicle Options: XJ, ZJ
Replaced By: 4897025AA
$187.00 $123.21
1
Add To Cart
2
4761060
YOKE, Pinion
- w/7290 Series Yoke(2 5/8"I.D.), w/Rear Disc Brakes
- Fitting Vehicle Options: ZJ
2
4762925
YOKE, Pinion
- w/1310 Series Yoke(2.97 O.D.), w/Rear Disc Brakes
- Fitting Vehicle Options: ZJ
2
4797552
YOKE, Pinion
- w/VM Diesel 1995-96
- Fitting Vehicle Options: XJ

3
83504946
SEAL, Pinion
$45.85 $30.63
1
Add To Cart

4
J3156063
CONE, Bearing

5
J3156062
CUP, Bearing

6

J3175779
SPACER, Pinion
$15.40 $10.44
1
Add To Cart

7
83503003
SHIM PACKAGE

8
J3156065
CUP, Bearing

9
J3170947
CONE, Bearing

10
4761676
GEAR SET, Ring and Pinion
3.55 Ratio
10
4761678
GEAR SET, Ring and Pinion
- 3.73 Ratio
- Replaced By: 4761678AB
$1015.00 $667.70
1
Add To Cart
10
83504938
GEAR SET, Ring and Pinion
- 4.11 Ratio
10
83505472
GEAR SET, Ring and Pinion
- 3.07 Ratio

11
83504374
BOLT PACKAGE

12
5252496
CASE PACKAGE, Differential, Also Includes Items #1 2,13,15,16 and 17.
3.55, 3.73, 4.11 Ratio
12
5252512
CASE PACKAGE, Differential, Also Includes Items #1 2,13,15,16 and 17.
- 3.07 Ratio

13
4773010
GEAR SET, Differential
- Replaced By: 5086171AB
$550.00 $376.20
1
Add To Cart

14

5252506
DISC PACKAGE, Differential
$377.00 $246.40
1
Add To Cart

15
83503004
SHIM PACKAGE (16)
- Replaced By: 68090828AB
$81.40 $56.31
1
Add To Cart

16
1937771
CONE, Bearing
- Require Quantity: 2
- Package Quantity: 1

17
J3171166
CUP, Bearing
- Require Quantity: 2

18
5252502
PIN, Retaining
$11.60 $7.83
1
Add To Cart

19

J8126500
BEARING PACKAGE, Differential Side
$165.00 $109.41
1
Add To Cart

20
5252507
BEARING PACKAGE, Pinion Inner
$148.00 $96.96
1
Add To Cart

21
5252508
BEARING PACKAGE, Pinion Outer
$153.00 $100.58
1
Add To Cart

Genuine Mopar Parts, the Right Choice

MoparPartsGiant.com offers the wholesale prices for genuine 1994 Jeep Cherokee parts. Parts like Differential - Locking are shipped directly from authorized Mopar dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 2.5L, 6 Cyl 4.0L. Transmission: 3-Speed Automatic Transmission, 4-Speed Automatic Transmission, 5-Speed Manual Transmission.
