Diagram (1 of 1): FRAME & BUMPERS SNOW PLOW LIFT RAM AND RESERVOIR, HYDRAULIC CJ, SJ CHEROKEE, SJ WAGONEER, J10, J20
1986 Jeep Wrangler Snow Plow Lift Ram & Reservoir Hydraulic Diagram
Enlarge Diagram
Sort by:
Ref No.
Ref No.
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
  • 1
    J8123577
    BRACKET
  • 2
    J8123578
    BAR
  • 3
    J8123733
    BAR
  • 4
    J8131071
    BRACKET
  • 5
    J8123731
    BAR
  • 6
    J8131072
    BRACE
  • 7
    J8123732
    BAR
  • 8
    J0122017
    BOLT
  • 9
    J0118664
    WASHER
  • 10
    J0103319
    WASHER, Lock
  • 11
    J0102634
    NUT
  • 12
    J0120380
    WASHER, Lock
  • 13
    J2130805
    PULLEY
  • 14
    S0120887
    BOLT
  • 15
    J8123575
    BRACKET
  • 16
    J2130947
    HOSE, 7' Required
  • 17
    J2005984
    RAM, Snow Plow Lift
  • 18
    J2130002
    FILTER
  • 19
    J8123576
    COUPLING
  • 20
    J2005606
    BRACKET
  • 21
    J2130954
    HOSE
    • 4' Required
  • 21
    J2130955
    HOSE
    • 5' Required
  • 22
    J2130951
    HOSE
    • 2' Required
  • 22
    J2130952
    HOSE
    • 5' Required
  • 23
    J2130140
    COUPLING
  • 24
    J0122007
    BOLT
    • Require Quantity: 4
  • 25
    J8123584
    BELT, Hydraulic Pump
    • Eight Cylinder Engine
  • 25
    J8123585
    BELT, Hydraulic Pump
    • Six Cylinder Engine
  • 26
    J8123892
    PULLEY
  • 27
    J2130143
    VENT
  • 28
    J0103320
    WASHER
  • 29
    J8123574
    TANK, Lift Cyinder
  • 31
    J0100114
    BOLT
Genuine Mopar Parts, the Right Choice
MoparPartsGiant.com offers the wholesale prices for genuine 1986 Jeep Wrangler parts. Parts like Snow Plow Lift Ram & Reservoir Hydraulic are shipped directly from authorized Mopar dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 2.5L, 4 Cyl 2.5L Diesel, 6 Cyl 4.2L. Transmission: 4-Speed Manual Transmission, 5-Speed Manual Transmission, Automatic Transmission.
