Make sure this part fits

Chrysler 5147260AB Bracket-Engine Mount

2011 Chrysler 200 5147260AB

Customer Questions & Expert Answers (9)
Mopar 5147260AB Bracket-Engine Mount
  • Part Description
    Bracket Engine Mount
  • Replaced By
    5147260AD
  • Manufacturer
    Mopar
Make sure this part fits
$16.57 MSRP: $24.60
You Save: $8.03 (33%)
1
ADD TO CART
  • Related Parts
  • Product Specifications
  • Vehicle Fitment
  • Customer Questions & Expert Answers
  • Product Specifications

    BrandGenuine Chrysler
    Manufacturer Part Number5147260AB
    Part DescriptionBracket Engine Mount
    Item Dimensions6.1 x 5.6 x 4.1 inches
    Item Weight2.30 Pounds
    ConditionNew
    ManufacturerMopar
    SKU5147260AB
    WarrantyThis genuine Mopar part is guaranteed by Mopar's factory warranty.
    Shipping & ReturnShipping Policy Return Policy
    Warning: California’s Proposition 65
  • Vehicle Fitment

    Year Make Model Engine Important vehicle option details
    2011 Chrysler 2004 Cyl 2.4LLimited Sedan, LX Convertible, LX Sedan, Touring Convertible, Touring Sedan
  • Customer Questions & Expert Answers

    Q:
    Will this fit my truck? Posted by MoparPartsGiant Specialist
    A:
    You can Select Your Vehicle to check if 5147260AB fits your vehicle.
    Posted by MoparPartsGiant Specialist
    Q:
    What are the four powertrain mounts and their functions for the 2014 Chrysler 200? Posted by Customer
    A:
    The four powertrain mounts are: 1. The front mount, which connects the transaxle to the crossmember. 2. The left mount, which secures the driver's side of the engine to the subframe. 3. The right engine mount, which attaches the engine block to the passenger's side of the subframe. 4. The rear mount, which links the engine block to the subframe.
    Posted by MoparPartsGiant Specialist
    Q:
    How many powertrain mounts are there and what are their functions for the 2011 Chrysler 200? Posted by Customer
    A:
    There are four powertrain mounts: 1. The front mount connects the transaxle to the crossmember. 2. The left mount secures the driver's side of the engine to the subframe. 3. The right engine mount attaches the engine block to the passenger's side of the subframe. 4. The rear mount links the engine block to the subframe.
    Posted by MoparPartsGiant Specialist
    See expert answers on similar Engine Mount
    Q:
    How do you check the powertrain mounts for the 2011 Dodge Avenger? Posted by Customer
    A:
    To check the mounts, the engine must be raised slightly to relieve weight from them. Begin by raising the vehicle and securely supporting it on jackstands. Then, remove the front wheels and tires. Position two jacks-one under the crankshaft pulley and the other under the transaxle bellhousing-using a block of wood to protect the components while raising the engine/transaxle just enough to relieve the mounts. Inspect the mounts for any cracks, hardened rubber, or separation from the metal plates, and check for movement between the mount plates and the engine or subframe. Tighten any loose fasteners as necessary. Applying rubber preservative can help slow deterioration.
    Posted by MoparPartsGiant Specialist
    Q:
    What is the process for replacing the rear mount for the 2011 Dodge Avenger? Posted by Customer
    A:
    For the rear mount replacement, remove the throttle body air inlet tube and air filter housing, raise the vehicle, and remove the rear mount bracket-to-transaxle bolts. Separate the bracket from the mount, remove the mount-to-subframe mounting bolts, and replace the mount with a new one. Install the bracket and through-bolt to the mount, then install the mount to the subframe and transaxle, tightening all bolts to the specified torque.
    Posted by MoparPartsGiant Specialist
    See expert answers on similar Engine Mount
    Q:
    What is required to replace the right engine mount for the 2012 Dodge Avenger? Posted by Customer
    A:
    The right mount requires removing the lower splash shield, engine ground strap, and specific fasteners before installing a new mount.
    Posted by MoparPartsGiant Specialist
    Q:
    What is the procedure for replacing the rear mount for the 2013 Chrysler 200? Posted by Customer
    A:
    For the rear mount, access the top rear of the engine compartment to remove the mounting bracket-to-block bolts. Then, raise the vehicle and take out the mount assembly. Replace it with a new one and secure it to the subframe and engine block with the appropriate torque.
    Posted by MoparPartsGiant Specialist
    Q:
    What steps are involved in replacing the left mount for the 2011 Dodge Avenger? Posted by Customer
    A:
    For the left mount, disconnect the negative battery cable, raise the vehicle, remove the middle engine splash shield and air filter housing, support the transaxle, and then remove the mounting bolts to replace the mount. Ensure to tighten the bolts to the specified torque.
    Posted by MoparPartsGiant Specialist
    Q:
    What does the engine mounting system on the 2014 Chrysler 200 consist of? Posted by Customer
    A:
    The engine mounting system consists of four molded mounts. The right and left mounts support the engine/transaxle assembly, while the front and rear mounts restrict the torquing action of the powertrain.
    Posted by MoparPartsGiant Specialist
    If you have any questions about this product, please don't hesitate to ask us. We will be happy to help you!

Genuine Mopar Part 5147260AB, the Right Choice

To ensure reliability, purchase Mopar part # 5147260AB Bracket-Engine Mount. It is sometimes referred to as Chrysler Engine Mount, Chrysler Engine Mount Bracket. For Mopar owners with dreams of keeping their vehicles running in prime condition, choosing OEM parts is a smart decision. Meticulously crafted, these parts follow strict factory specifications and are manufactured in top-notch facilities with advanced technologies. Furthermore, they undergo rigorous testing to ensure durability and safety, making them a reliable choice for Mopar owners. This part fits specific Chrysler 200 models.

MoparPartsGiant.com is a leading supplier of genuine Mopar parts and accessories such as Mopar 5147260AB Bracket-Engine Mount. Wondering where to find exceptional quality and affordable OEM Mopar parts? You have already come to the right place. Our website boasts a huge selection of genuine Mopar parts at the most economical prices possible. What's more, all parts come with a manufacturer's warranty. For detailed Chrysler parts information, click here.
