Q: Where is the EGR Valve and EGR Tube Located and How to Remove and Install It?
A: The EGR valve, if equipped, is located on the front of the right cylinder head. To remove the EGR valve on 2010 and earlier models, remove the air intake duct and air filter housing. Disconnect the electrical connector by sliding the red lock forward, depressing the release tab, and pulling off the connector. Remove the EGR tube mounting flange bolts and the EGR valve mounting bolts. Clean the mating surfaces and install a new gasket and place the EGR valve against the cylinder head and tighten the nuts. Next, connect the cooler hose and install the clamp, reconnect the electrical connector, and install the engine cover.
