How Do You Remove and Install a Ignition Coil on Dodge Grand Caravan?

To remove a conventional coil, start by detaching the cable from the negative battery terminal. Then, mark the wires and terminals with numbered tape and remove the primary wires and high-tension cable from the coil. If it's a four-cylinder engine, disconnect the primary electrical connector and high-tension cable, and remove the mounting bolts. For an earlier type coil on the fenderwell, disconnect the primary wires and high-tension cable, and remove the mounting bracket bolts. If the coil is bad, loosen the clamp pinch screw and transfer the clamp/mounting bracket to the new coil. Make sure to release the locking tab on the electrical connector for the primary wires on the later type engine-mounted coil before disconnecting it. On 3.0L engines, remove the mounting bolts from the intake plenum and intake manifold. Disconnect the coil mounting bracket, remove the coil/bracket assembly, clean the outer case, and check for cracks or damage. Clean the coil primary terminals and check the coil tower terminal for corrosion, using a wire brush if necessary. Check the coil primary resistance by attaching the leads of an ohmmeter to the positive and negative terminals. Check the coil secondary resistance by hooking one ohmmeter lead to a primary terminal and the other lead to the large center (high-tension) terminal. If the measured resistances are not as specified, the coil is likely defective and should be replaced. To install the coil, hook up the wires and attach the cable to the negative battery terminal. For a Direct Ignition System (DIS) coil pack on 3.3L and 3.8L engines, start by labeling the six spark plug wires and measuring the resistance of each cable. It should be 3 to 12 k-ohms per foot of cable, replacing any cable not within this range. Remove the four coil pack mounting bolts, lift up the coil pack, and unplug the electrical connector. Measure the resistance on the primary side of each coil with a digital ohmmeter, making sure the test lead probes have good contact with the terminals. Connect an ohmmeter between the B+ pin and the pin corresponding to the particular cylinder at the coil. Measure the secondary resistance of the coil between the paired high tension towers of each group of cylinders. If any coil in the coil pack fails either of the above tests, replace the coil pack. Installation is the reverse of removal.

Genuine Dodge Grand Caravan Ignition Coil

Ignition Coil Resistor

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

17 Ignition Coils found

View related parts
Dodge Grand Caravan Coil-Ignition
Part Number: 5149168AJ
$40.96 MSRP: $60.20
You Save: $19.24 (32%)
ADD TO CART
Product Specifications
- Other Name: Coil Assembly, Ignition Coil
- Replaces: 5149168AI, 5149168AH
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2011-2020 Dodge Grand Caravan | C/V, Crew, Express, GT, LUX, Mainstreet, R/T, SE, SXT | 6 Cyl 3.6L
View related parts
Dodge Grand Caravan Electrical Ignition Coil
Part Number: 5149168AI
$40.32 MSRP: $60.20
You Save: $19.88 (34%)
ADD TO CART
Product Specifications
- Other Name: Coil-Ignition
- Replaced by: 5149168AJ
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2012-2019 Dodge Grand Caravan | Crew, GT, R/T, SE, SXT | 6 Cyl 3.6L
View related parts
Dodge Grand Caravan Ignition Coil
Part Number: 56032520AC
$115.44 MSRP: $176.00
You Save: $60.56 (35%)
ADD TO CART
Product Specifications
- Other Name: Coil/Ign-Ignition
- Replaced by: 56032520AF
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2004-2009 Dodge Grand Caravan | C/V, EL, ES AWD, ES FWD, EX, SE, Sport AWD, Sport FWD, SXT, SXT AWD, SXT FWD | 6 Cyl 3.3L, 6 Cyl 3.8L
View related parts
Dodge Grand Caravan Ignition Coil
Part Number: 4606869AB
$62.55 MSRP: $94.20
You Save: $31.65 (34%)
ADD TO CART
Product Specifications
- Other Name: Coil/Ign-Ignition
- Replaced by: 4606869AD
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2008-2010 Dodge Grand Caravan | Crew, SXT | 6 Cyl 4.0L
View related parts
Dodge Grand Caravan Ignition Coil Replacement
Part Number: 56032520AE
$115.44 MSRP: $176.00
You Save: $60.56 (35%)
ADD TO CART
Product Specifications
- Other Name: Coil/Ign-Ignition
- Replaced by: 56032520AF
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2010 Dodge Grand Caravan | C/V, Crew, Hero, SE, SXT | 6 Cyl 3.3L, 6 Cyl 3.8L
View related parts
Dodge Grand Caravan Ignition Coil
Part Number: 5149168AH
$40.32 MSRP: $60.20
You Save: $19.88 (34%)
ADD TO CART
Product Specifications
- Other Name: Coil-Ignition
- Replaced by: 5149168AJ
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2011 Dodge Grand Caravan | C/V, Crew, Express, LUX, Mainstreet, R/T | 6 Cyl 3.6L
View related parts
Dodge Grand Caravan Ignition Coil
Part Number: 4609103AB
$143.19 MSRP: $217.00
You Save: $73.81 (35%)
ADD TO CART
Product Specifications
- Other Name: Coil/Ign-Ignition
- Replaced by: 4609103AC
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2004-2007 Dodge Grand Caravan | C/V, EL, SE, Sport FWD
View related parts
Dodge Grand Caravan Ignition Coil
Part Number: 5269670
$143.19 MSRP: $217.00
You Save: $73.81 (35%)
ADD TO CART
Product Specifications
- Other Name: Coil/Ign-Ignition
- Replaced by: 4609103AC
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 1997-2003 Dodge Grand Caravan | Base, C/V, EL, ES FWD, LE FWD, SE, SE FWD, Sport FWD | 4 Cyl 2.4L
View related parts
Dodge Grand Caravan Ignition Coil
Part Number: 4609140AB
$7.90 MSRP: $169.00
You Save: $161.10 (96%)
ADD TO CART
Product Specifications
- Other Name: Coil/Ign-Ignition
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 1999-2000 Dodge Grand Caravan | Base, ES AWD, ES FWD, LE AWD, LE FWD, SE AWD, SE FWD, Sport AWD | 6 Cyl 3.3L, 6 Cyl 3.8L
View related parts
Dodge Grand Caravan Ignition Coil Spark Plug Wire
Part Number: V7203971AA
$64.24 MSRP: $83.02
You Save: $18.78 (23%)
ADD TO CART
Product Specifications
- Other Name: Coil/Ign-Ignition ; Coil, Ign., D.I.S.
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 1990-1998 Dodge Grand Caravan | Base, LE AWD, LE FWD, SE AWD, SE FWD | 4 Cyl 2.4L, 4 Cyl 2.5L, 6 Cyl 3.0L, 6 Cyl 3.3L, 6 Cyl 3.8L
View related parts
Dodge Grand Caravan Ignition Coil Boots And Spring
Part Number: 4609088AF
$92.19 MSRP: $141.00
You Save: $48.81 (35%)
ADD TO CART
Product Specifications
- Other Name: Coil/Ign-Ignition
- Replaced by: 4609088AI
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2001 Dodge Grand Caravan | ES FWD, Sport FWD
View related parts
Dodge Grand Caravan COIL/IGN-D.I.S.
Part Number: 4609080
$119.34 MSRP: $151.86
You Save: $32.52 (22%)
ADD TO CART
Product Specifications
- Other Name: Coil, 4-Cyl., 2.2 TBI - 2.5 Turbo, (Insul. 4638991) (Optional w/5234610 Toyodenso); Cable Set, Coil, Ignition Coil
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 1995-1996 Dodge Grand Caravan | Base, LE AWD, LE FWD, SE AWD, SE FWD | 4 Cyl 2.4L, 6 Cyl 3.0L, 6 Cyl 3.3L, 6 Cyl 3.8L
View related parts
Dodge Grand Caravan Ignition Coil
Part Number: MD101644
$59.20 MSRP: $75.33
You Save: $16.13 (22%)
ADD TO CART
Product Specifications
- Other Name: Coil V6 Asm Ignition ; Coil, Ignition; Cable Set, Coil
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 1987-1989 Dodge Grand Caravan | 4 Cyl 2.2L, 4 Cyl 2.5L, 4 Cyl 2.6L, 6 Cyl 3.0L
View related parts
Dodge Grand Caravan Ignition Coil Replacement
Part Number: 4176009
Product Specifications
- Other Name: Coil-Ignition Assy; Coil, Ignition Coil
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 1987-1989 Dodge Grand Caravan | 4 Cyl 2.2L, 4 Cyl 2.5L, 4 Cyl 2.6L, 6 Cyl 3.0L
View related parts
Dodge Grand Caravan Ignition Coil
Part Number: 4443971
Product Specifications
- Other Name: Coil/Ign-Ignition ; Coil, Ign., D.I.S.; Coil
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 1990-1998 Dodge Grand Caravan | Base, LE AWD, LE FWD, SE AWD, SE FWD | 4 Cyl 2.4L, 4 Cyl 2.5L, 6 Cyl 3.0L, 6 Cyl 3.3L, 6 Cyl 3.8L
View related parts
Dodge Grand Caravan Ignition Coil Replacement
Part Number: 56032520AB
Product Specifications
- Other Name: Coil/Ign-Ignition
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 2001-2003 Dodge Grand Caravan | C/V, EL, ES AWD, ES FWD, EX, SE, Sport AWD, Sport FWD | 6 Cyl 3.3L, 6 Cyl 3.8L
View related parts
Dodge Grand Caravan Ignition Coil
Part Number: MD141044
Product Specifications
- Other Name: Coil/Ign-Ignition ; Coil, 4-Cyl.; Coil
- Warranty: This genuine part is guaranteed by Mopar's factory warranty.
Fits the following Vehicles:
- 1990-2000 Dodge Grand Caravan | Base, LE AWD, LE FWD, SE AWD, SE FWD | 4 Cyl 2.4L, 4 Cyl 2.5L, 6 Cyl 3.0L, 6 Cyl 3.3L, 6 Cyl 3.8L

Dodge Grand Caravan Ignition Coil

There are certain parts of Automobiles that are deemed necessary for the proper functioning of automobiles and one of the parts installed in Dodge Grand Caravan vehicles is the Ignition Coil. The ignition coil on the other hand boosts the power from the battery's low voltage to high voltage needed to cause spark that ignites the air/fuel mixture in the cylinders. It uses an iron core in a housing which has two coils of insulated copper wire, the primary and the secondary. The primary circuit intervened the battery and the trigger device, the secondary circuit comprises the high tension lead and spark plug cables. Various kinds of ignition coils for instance the distributor ignition systems or the coil on plug systems have been installed in previous Grand Caravan models. Misfiring or a dead ignition coil, can contribute to a rough idle, poor performance, and fuel economy, thus it is mandatory to check this component regularly for its performance in enhancing the functionality of your vehicle.

Looking for affordable and high-quality auto parts? Then you have already arrived at the proper online shop. We offer all Dodge Grand Caravan Ignition Coil at great affordable prices. Moreover, all genuine Dodge Grand Caravan Ignition Coil come with a manufacturer's warranty. In the long run, you would realize you have saved a lot of trouble and money with OEM parts from here.

Dodge Grand Caravan Ignition Coil Parts Questions & Experts Answers

Ignition Coil
4606869AB
Q: How Do You Remove and Install a Ignition Coil on Dodge Grand Caravan?
A: To remove a conventional coil, start by detaching the cable from the negative battery terminal. Then, mark the wires and terminals with numbered tape and remove the primary wires and high-tension cable from the coil. If it's a four-cylinder engine, disconnect the primary electrical connector and high-tension cable, and remove the mounting bolts. For an earlier type coil on the fenderwell, disconnect the primary wires and high-tension cable, and remove the mounting bracket bolts. If the coil is bad, loosen the clamp pinch screw and transfer the clamp/mounting bracket to the new coil. Make sure to release the locking tab on the electrical connector for the primary wires on the later type engine-mounted coil before disconnecting it. On 3.0L engines, remove the mounting bolts from the intake plenum and intake manifold. Disconnect the coil mounting bracket, remove the coil/bracket assembly, clean the outer case, and check for cracks or damage. Clean the coil primary terminals and check the coil tower terminal for corrosion, using a wire brush if necessary. Check the coil primary resistance by attaching the leads of an ohmmeter to the positive and negative terminals. Check the coil secondary resistance by hooking one ohmmeter lead to a primary terminal and the other lead to the large center (high-tension) terminal. If the measured resistances are not as specified, the coil is likely defective and should be replaced. To install the coil, hook up the wires and attach the cable to the negative battery terminal. For a Direct Ignition System (DIS) coil pack on 3.3L and 3.8L engines, start by labeling the six spark plug wires and measuring the resistance of each cable. It should be 3 to 12 k-ohms per foot of cable, replacing any cable not within this range. Remove the four coil pack mounting bolts, lift up the coil pack, and unplug the electrical connector. Measure the resistance on the primary side of each coil with a digital ohmmeter, making sure the test lead probes have good contact with the terminals. Connect an ohmmeter between the B+ pin and the pin corresponding to the particular cylinder at the coil. Measure the secondary resistance of the coil between the paired high tension towers of each group of cylinders. If any coil in the coil pack fails either of the above tests, replace the coil pack. Installation is the reverse of removal.
